High Brightness 10.4'' Waterproof Panel PC 4GB With Capacitive Touch Screen

Name: High Brightness 104 Waterproof Panel PC 4GB With Capacitive Touch Screen
Brand: ITD/OEM
Price: 1 USD

Buy cheap High Brightness 10.4'' Waterproof Panel PC 4GB With Capacitive Touch Screen product

Brand Name : ITD/OEM

Model Number : ITD10PPCT1HBFJ1

Certification : CE, FCC, RoHS

Place of Origin : China

MOQ : 1PCS

Price : TBA

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 5000PCS/Month

Delivery Time : 15-20 Business Days

Packaging Details : 1-5pcs/CTN, Safe, Firm

advantage : touch screen

Color : Black or Silver

Housing Type : open frame Mount, VESA Mounting

MTBF : 50000Hours

name : touch panel pc

Resolution : 800*600

Contact Now

High Brightness 10.4'' Waterproof Panel PC 4GB With Capacitive Touch Screen

ITD Waterproof panel PC rugged marine grade high brightness LCDs are designed for use in marine environments. These devices are ready to be panel-mounted into a console. Its front bezel provides maximum protection from water and other elements as it meets various NEMA and IP rating standards. It delivers high performance computing power with its Intel processors.

Waterproof Panel PC BENEFITES

- 10.4" Very Bright Active Matrix Sunlight Readable TFT Display; 1000 nits (cd/m2)

- High-Luminance Solid-State LED-enhanced Backlighting

- Energy Efficient, Low Power Consumption

- High Environmental Performance and Reliability

- 4GB, Max.8G System Memory

- 500GB HDD or 126GB SSD, Bigger Capacity Optional

- Resistive Touch Screen Standard (PCAP, IR Touch Optional)

- Wide Operational Temperature Range, -10°C to +60°C

Open Frame High Brightness Panel PC
Model Name		ITD10PPCG1HBF**
IP Rating		N/A
PC Systems Options
ARM Android Based RK3288(RK3368 optional)	X86 Windows Based		X86 Windows Based
CPU: Quad-Core Cortex-A17 1.8GHz	CPU: Intel® Celeron J1900		CPU: Intel Core i3/i5/i7
Chipset: N/A	Chipset: Intel® NM10 Express		Chipset: Intel® HD Graphics, Support 1080p
Memory: 1G/2G	Memory: 2GB(Max. 8GB)		Memory: 2GB(Max. 8GB)
HDD/SSD: 8G	HDD/SSD:500G/64G		HDD/SSD:500G/64G
1×HDMI	1×VGA, 1×HDMI		1×VGA, 1×HDMI
1×USB 2.0	2×USB 2.0, 2×USB3.0		2×USB 2.0, 2×USB3.0
1×mini-SD slot	1×COM(RS232/422/485)		1×COM(RS232/422/485)
1×LAN	1×LAN		1×LAN
1×Audio Out	1×Audio Out, 1×MIC In		1×Audio Out, 1×MIC In
Expansion: SSD	Expansion: USB, COM, Mini-PCIe		Expansion: USB, COM, Mini-PCIe
LCD Panel
Screen Diagonal (Inch/cm)		10.4”
Display Active Screen Size (mm)		211.2(H)X158.4(V)
Aspect Ratio		4:3
Physical Resolution		800×600(1024×768 optional)
Maximum Resolution Supported		1920X1080
Colors		16.7M
Brightness (cd/m²)		1000(1500 Optional)
Contrast Ratio		600:1
View Angels		70/70/60/60
Backlight/Backlight Lifetime		LED Backlight with 50000 Hours’ Lifetime
Touch Panel
Touch Options		Resistive, IR, PCAP, SAW
Touch Drivers		Windows, Linux, Android, Mac, Raspberry Pi
Operation
Operating Temperature Range		-10~60°C (-20~70°C Optional)
Humidity Range (RH)		10-90%
24/7/365 Use		Supported
Power
Power Indicator		Green LED
Power Input		DC 12V
Power Consumption		30W
Order Information
10.4”1000nits Open Frame Panel PC with Resistive Touch, J1900		ITD10PPCT1HBFJ1
10.4”1000nits Open Frame Panel PC with PCAP Touch, J1900		ITD10PPCT5HBFJ1
10.4”1000nits Open Frame Panel PC with IR Touch, J1900		ITD10PPCT2HBFJ1
10.4”1000nits Open Frame Panel PC with Tempered Glass, J1900		ITD10PPCG1HBFJ1
10.4”1000nits Open Frame Panel PC with Resistive Touch, i5		ITD10PPCT1HBFI5
10.4”1000nits Open Frame Panel PC with PCAP Touch, i5		ITD10PPCT5HBFI5
10.4”1000nits Open Frame Panel PC with IR Touch, i5		ITD10PPCT2HBFJ1
10.4”1000nits Open Frame Panel PC with Tempered Glass, i5		ITD10PPCG1HBFI5

APPLICATION
High Brightness 10.4'' Waterproof Panel PC 4GB With Capacitive Touch Screen

OUR FACTORY
High Brightness 10.4'' Waterproof Panel PC 4GB With Capacitive Touch Screen
